Description
Optimum Bench Drill 230V (D17PRO) Germany | Model: D17PRO
Features:
- Industrial engine
- Easy to use safety switch according to IP 54
- Digital drilling depth and speed indicator integrated in the housing
- Separate emergency stop impact switch
- Precision Spindle bore
- Safety electronics in 24 V DC
- Guaranteed concentricity measured less than 0.02 mm in the drill quill
- Drill spindle with precision ball bearings
- High quality keyless chuck
- Digital depth gauge
- Precision machined, stable drill table with diagonal T-slots and circumferential cooling water channel
- V-belt cover with safety switch
- One piece cast aluminum die-cast quill lever with softgrip handles
- Large, height-adjustable protective screen with safety switch
- Heavy version of the entire machine
Specifications:
| Dimensions and weights | |
| Column diameter | 60 mm |
| Length approx. | 585 mm |
| Width/depth approx. | 305 mm |
| Height approx. | 840 mm |
| Weight approx. | 39,5 kg |
| Drilling performance | |
| Drilling performance steel (S235JR) | 16 mm |
| Continuous drilling performance steel (S235JR) | 12 mm |
| Drilling table | |
| Workspace length | 235 mm |
| Workspace width | 220 mm |
| T-groove size | 12 mm |
| Rotation | 360 ° |
| Angle | 45 ° |
| Max. distance spindle – drilling table | 325 mm |
| Electrical Data | |
| Drive motor output | 0,5 kW |
| Supply voltage | 230 V |
| Mains frequency | 50 Hz |
| Machine base | |
| Max. distance spindle – machine base | 530 mm |
| Work area length | 220 mm |
| Work area width | 230 mm |
| Machine base T-groove size | 16 mm |
| Machine base T-groove number | 2 |
| Machine base T-groove spacing | 148 mm |
| Speed range | |
| Speed range | 680 2700 min¯¹ |
| Number of gears | 5 Stufen |
| Spindle | |
| Quill stroke | 65 mm |
| Spindle chuck | MT 2 |
| Reach | 152 mm |
| VPE | 1 |
